Description
TECHNICAL SPECIFICATIONS
PORTS AND INTERFACES
Swytch Hub
Power
HDMI 2.0 to Display
HDMI 2.0 to Meeting Room Computer
USB 3.0 Type A to Conference Camera
USB 3.0 Type C to Meeting Room Computer
USB 3.0 Type C to Swytch Extender
Swytch Extender
Power
USB 3.0 Type A to Swytch Hub
USB 3.0 Type C to Swytch Connector
USB 3.0 Micro B to Swytch Connector
Swytch Connector
USB 3.0 Type A to laptops with Type A ports
USB 3.0 Type C to laptops with Type C ports
MOUNTS
Swytch Hub: Compatible with Logitech PC Mount (not included)
Swytch Extender: Mount through a 25 mm grommet hole or attach below the table with included hardware
Swytch Connector: Magnetic dock included
GENERAL SPECIFICATIONS
Number of Meeting Room Displays: 1
Maximum Resolution and Frame Rate, Display: 4K/60 fps
Maximum Resolution and Frame Rate, Camera: 4K/30 fps
Laptop Audio for Local Sharing: Yes
Laptop Audio for Online Meetings: Yes (with services that support content sharing with system audio)
Device Management: Remote monitoring and management via Logitech Sync
COMPATIBILITY
Conference Cameras
• Works with conference cameras that connect via USB, including Logitech Rally, MeetUp, and GROUP
Room Solutions
• Microsoft Teams Rooms
• Zoom Rooms
• Also compatible with other room solutions that use USB-connected conference cameras and an HDMI-connected display.
DIMENSIONS
Swytch Hub
Height: 27.4 mm
Width: 164 mm
Depth: 90 mm
Swytch Extender
Height: 27.4 mm
Width: 120 mm
Depth: 120 mm
SYSTEM REQUIREMENTS
Meeting Room Equipment
Display with HDMI input
USB conference cameras with speakerphone
Laptop Computers
USB 3.0 Port (Type A or Type C)
USB Power Delivery (Up to 60 watts) for compatible laptops that charge via USB Type C
Operating Systems with DisplayLink Plug and Display™ Drivers, including Windows 10, macOS 10.15 and later, and Chrome OS™ 75 or later.
PACKAGE CONTENTS
Swytch Hub
Swytch Extender
Swytch Connector with 1.5 m USB Cable
100-240v Swytch Hub Power Supply
100-240v Swytch Extender Power Supply
5 m USB 3.0 Cable
2.2 m USB 3.0 Cable
2.0 m HDMI 2.0 Cable
Mounting accessories
Documentation
